Suppliers of aluminum plate (1mm-20mm)

Aluminum plates are aluminum materials with a thickness of more than 0.2mm and less than 500mm, a width of more than 200mm, and a length of less than 16m. With the advancement of large-scale equipment, there are more aluminum plates with a maximum width of 600mm).
Aluminum plate refers to a rectangular plate rolled from aluminum ingots. It is divided into pure aluminum plate, alloy aluminum plate, thin aluminum plate, medium-thick aluminum plate and patterned aluminum plate.

product details

technical parameters

Aluminum plate technical parameters (commonly used models)

Aluminum Plate model Temper Thickness(mm) Width(mm) Length(mm)

1050 Aluminum plate H111, H112, H14, H18, H19, H22, H24, H26, H28 0.2mm-500mm 20mm-2630mm customized

1060 Aluminum plate H111, H112, H14, H18, H19, H22, H24, H26, H28, etc. 0.1-500mm 20mm-2640mm 500-10000mm

1100 Aluminum plate O, H14, H16, H24, H22, H112, H111, H26, H12, H28, etc. 0.1-500mm 0.1-500mm 500-16000mm

2024 Aluminum plate T3, T4, T6, T72, T81, T351, T861, T3511, T8611, HO 0.1mm-550mm 700mm-2650mm 500-11000mm

3003 Aluminum plate HO, H12, H14, H16, H18, H19, H22, h24, h26, H28, H112, etc. 0.2mm-450mm 50mm-2650mm 500-12000mm

5005 Aluminum plate H12, H14, H16, H18, H22, h24, h26, H28, H36, H38, etc. 0.2mm-600mm 30mm-2650mm 500-12000mm

5052 Aluminum plate H12, H14, H16, H18, H22, h24, h26, H28, H36, H38, etc. 0.2mm-500mm 60mm-2650mm 500-10000mm

5083 Aluminum plate H111, H114, H116, H321, H22, H24, H26, H32, H16, H12, HO, etc. 0.15mm-500mm 30mm-2600mm 500-9000mm

6061 Aluminum plate HO, F, T4, T6, T651 0.35mm-500mm 500mm-2600mm 600-11000mm

6063 Aluminum plate O,T6,T651,T4 0.15-600mm 500mm-2800mm 500-16000mm

7050 Aluminum plate HO, F, T112, T651, T6, T7451 1.0mm-600mm 600mm-2500mm 600-8000mm

7075 Aluminum plate HO, T651, T7451, T6, etc 15.0mm-600mm 500mm-2600mm 600-8000mm

Application

Can cut carbon steel, stainless steel, copper, aluminum and other pipes and profiles, such as: the tube, pipe, oval pipe, rectangular pipe, H-beam, I-beam, angle, channel, etc. The device is widely used in various kind of pipes profile processing field, shipbuilding industry, network structure, steel, marine engineering, oil pipelines and other industries.
